Product Details:
|
| Color: | Silvery | Inside Dimension: | 14m*12m*0.3m |
|---|---|---|---|
| Heating Capacity: | 400000kcal/h | Max Curing Temperature: | 350℃ |
| Temperature Uniformity Control: | ±5℃ | Avg.heating Up Time: | 40min |
| Max Load Capacity/mesh-belt: | 200kg/㎡ | Max Output: | 8000kg/h |
| High Light: | Solidification Curing Furnace,adjustable temperature Curing Furnace,adjustable temperature Curing oven |
||
1. Technological process:
Loading→Leveling→Drying(Pre-heating)→Curing→Cooling and unloading
2. Main structure:
Mainly structured of Loading and uncloading sections , HL Cooling System, Convey Unit, Body, Hot Blast Air Generating and Circulating Systems, Electric Control System and so on. High-automaticly controlled with the speed of mesh-blet regulated, it can fully satisfy all curing processes.
3. Main parameter : (Based on M10)
| Outsiade dimension | 23×15.9×16.6 | m |
| Inside dimension | 14×12×0.3 | m |
| Max curing temperature | 350 | ℃ |
| Temperature uniformity control | ±5 | ℃ |
| Max load capacity/mesh-belt | 200 | kg/m² |
| Avg.gas consumption | 20 | m³/h |
| Max output | 8000 | kg/h |
| Belt convey speed | 0.23~0.52 | m/min |
Company research and development center is located in changzhou national hi-tech zone, owns 15 acres of land for construction and is built around five categories of chemicals and equipment research and development and incubation bases, equipped with standardization on the basis of the experimental equipment and testing equipment of the company's marketing center and two functional departments in the changzhou new north area to create building, the company's three big center and subsidiary system solution for customer demand to provide a solid foundation. The company has passed ISO9001 and TS16949 system certification.
