Double Combustion Curing Furnace Save Aeration Consumption FGG1612 For Zinc Flake Coating

Double Combustion Curing Furnace Save Aeration Consumption FGG1612 For Zinc Flake Coating
Double Combustion Curing Furnace Save Aeration Consumption FGG1612 For Zinc Flake Coating

Large Image :  Double Combustion Curing Furnace Save Aeration Consumption FGG1612 For Zinc Flake Coating

Product Details:
Place of Origin: Changzhou in china
Brand Name: JUNHE
Certification: ISO9001 CE
Model Number: FGG1612
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: 40 HQ
Delivery Time: Two months after receipt of advance payment
Supply Ability: 2 Sets per Month

Double Combustion Curing Furnace Save Aeration Consumption FGG1612 For Zinc Flake Coating

Description
Color: Silvery Inside Dimension: 18m*12m*0.3m
Heating Capacity: 100000+450000kcal/h Max Curing Temperature: 350℃
Temperature Uniformity Control: ±5℃ Avg.heating Up Time: 30min
Max Load Capacity/mesh-belt: 300kg/㎡ Max Output: 10000kg/h
High Light:

Heat Treatment Furnace

,

Galvanic Zinc Coating

Save aeration consumption Double Combustion Curing Furnace For Zinc Flake Coating Max curing temperature 350℃ Inside dimension 16m*12m*0.3m

Product Description


1. Technological process:



Loading→Leveling→Drying(Pre-heating)→Curing→Cooling and unloading



2. Main structure:



Mainly structured of Loading and uncloading sections , HL Cooling System,Convey Unit,Body, Hot Blast Air Generating and Circulating Systems, Electric Control System and so on. High-automaticly controlled with the speed of mesh-blet regulated,it can fully satisfy all curing processes.



3. Main parameter : (Based on M10)



Outsiade dimension 29×15.9×16.6 m
Inside dimension 18×12×0.3 m
Max curing temperature 350
Temperature uniformity control ±5
Max load capacity/mesh-belt 300 kg/m²
Avg.gas consumption 28 m³/h
Max output 10000 kg/h
Belt convey speed 0.3~0.67 m/min





We Have A Well-Experienced Team To Manufacture Curing Furnace And A Professional Design Institute. With Rich Experiences In Metal Coating Line Field And Numbers Of Professional Engineers, We Have Designed And Developed Many Types Of Machinery And Equipments Including Dip Spin Coating Machine , Etc.
Due To Our Good Credit And Service, , We Have Made Great Achievements In The Past Years. We Have Established Long-Term Business Relations With Many Customers And Some Of Our Overseas Customers Have Appointed Us To Be Their Purchase Agency In China. Our Products Are Exported To Many Countries & Areas, Such As Korea, India, Indonesia, Pakistan, Thailand, Vietnam, Iran, Japan, Denmark, Romania, Bulgaria, Russia, South Africa, Nigeria, The USA, Australia, Canada, Argentina And Chile.
In China You Can Get Your Desired Goods With The Best Prices And Good Quality. Welcome Your Enquiries From All Over The World.
