Product Details:
|
Color: | Silver | Coating Method: | Dip And Spray Coating |
---|---|---|---|
PH(20℃): | 5.0-8.0 | Specific Gravity: | 1.30-1.40 (spray Coating ) |
Viscosity: | According To Operating Demand | Operating Temperature: | 22±2℃ |
High Light: | Zinc Nickel Plating,Mechanical Zinc Plating |
JH-9610is made up of three packs: A,B and C;
Pack A: It is silver gray slurry that mainly chemically combined with super fine flake Zn, super fine flake Al and organic additive.
Pack B: It is water solution that mainly combined with corrosion protecion additive, particular regulator water solution etc.
Pack C: It is the tackifier of the coating which mainly made up of cellulose white or yellowish powder.
Performance Charcteristic:
1. Chrome free
2. Good surface finish performance,high anti-corrosion,low friction coefficient.
3. No hydrogen brittleness,no pickling process.
4. Good heat resistance.
5. Good SST hours ,anti-aging cycle is long, can coat more products under the same process conditions.
Coating Process:
1. Mix Ratio
Pack A: Pack B: Pack C=1:1: X(according to different viscosity demand )
2. Before Mixture, Keep weighted A&B into the water bath at 25±2℃ , then stir A to make metal slurry disperse uniformly by frequency mixer ,after A is fully evenly dispersed, reduce the agitating speed to 60r/min, and add B.
3. Add B to the stirring A slowly.
4. Stir the mixture about 1~2 hours after B added, then add C. C should be powdered if lump exist.(The barrel temperature should not be lower than 20℃, otherwise C will not be dissolved sufficiently .)Then stir 10~12 hours alowly and continuously.
Technical data:
No. | Item | Data |
1 | Color | Silver |
2 | Coating method | Dip and spraying |
3 | PH | 4.8-7.5 |
4 | Specific gravity | 1.45±0.1(Spray Coating) |
5 | Viscosity | 25~40s(Spray Coating) |
Mix Diagram:
Caution: Temperature should be controlled in above operation.
Coating Process:
